EXS-306 Semi Automatic Strapping Machine

If you want to improve efficiency in your warehouse, this enclosed EXS 306 semi-automatic machine is ideal for users who apply strapping on a daily basis. Simple to operate, feed the strap around the package and the machine automatically tensions and heat seals the strap. Accepts polyprop machine strapping form 6mm - 16mm wide on 200mm or 280mm cores.

Designed to provide a quick and efficient method of strapping single or multiple packages of varying sizes. This semi automatic also has external tension control, a safety cut-out switch when the top is opened and an enclosed cabinet design that keeps the strapping clean and dust free.

Features

• Enclosed Cabinet for added protection of machine components
• Quadruple access doors for easy access and serviceability
• Simple to use - Minimal Operator Training
• Tension Control Wheel (up to 150 lbs.)
• Fast Warm-Up Time
• Sealing Method - Heat Seal with Temperature Sealing Control (Caution! Up to 320 C / 608 F)
• Feed Length Control for auto-feeding
• Equipped with Reset and Manual Feed Buttons.
• Casters with brakes
• For Poly Strapping of 1/4 inch, to 5/8 inches (6 to 15 mm) width
• Approximate cycle time 1.5 seconds (Depends on package size and tension adjustment)

Technical Specifications

• Power: 1 Phase, 110/220V, 50/60Hz
• Strap Width: 9, 12, 15 mm (adjustable) (6mm option)
• Strapping Tension: 15 ~ 50 kgs
• Strappping Speed: 2.0 sec./strap
• Strapping Size: Min. : 60 mm, Max. : Any size
• Table Height: 750 mm
• Machine Size: L910 x W580 x H750 mm

Advice

1 year warranty. Allow 2-3 days for delivery. For expert advice and guidance on high performance automatic strapping machines, call our team of machine specialists on 9945919846
